Being only a test of the base architecture, the main objectives of the deployment were to ascertain the operating conditions (temperature and humidity), as well as to periodically monitor the tower’s vibrations. The following figures show the time plots of variables such as temperature, humidity and acceleration on the different axes. Based on these results it was possible to establish the vibration alert levels (vibration levels that could indicate an anomalous situation of the tower).
Figure 7- Time plot of temperature and humidity
Figure 8- Time plot of the acceleration on the X axis
Figure 9- Time plot of the acceleration on the Y axis
Figure 10- Time plot of the acceleration on the Z axis
